Product Details:
|
| Warranty: | 5 Years | After-sale Service: | Online Technical Support |
|---|---|---|---|
| Application: | Hotel | Material: | Sandwich Panel, Steel, Wooden,Log, Other, Wooden |
| Use: | Hotel | Product Type: | Modified Shipping Container |
| Design Style: | Farmhouse | Product Name: | Container Houses Home |
| Keyword: | Mobile Living Container House | Color: | Customized Color |
| Size: | 20ft 0r 40ft | Advantage: | Environmental Protection Low Cost Recycle |
| Type: | Assembled Fat Pack Container House | Usage: | Workshop Warehouse Construction Office |
| Window: | Aluminum Window | Structure: | Steel Luxury Container House |
|
40ft Expandable house Specifications
|
|
|
|
|||
|
Dimensions
|
External dimensions(mm)
|
W6400*L11600*H2480(lower side 2270)
|
|
|||
|
|
Internal dimensions(mm)
|
W6280*L11200*H2280(lower side 2150)
|
|
|||
|
|
Folded(mm)
|
W2160*L11600*H2480
|
|
|||
|
|
Total weight(kg)
|
4800kg
|
|
|||
|
Structure
|
Top side beam
|
t2.5mmQ235B
|
|
|||
|
|
Bottom side member
|
t2.5mmQ235B
|
|
|||
|
|
End side beam
|
t2.5mmQ235B
|
|
|||
|
|
Side wall frame
|
t2.5mmQ235B
|
|
|||
|
|
Subframe
|
t2.5mmQ235B
|
|
|||
|
|
Hanger
|
t4mmQ235B
|
|
|||
|
|
Folding hinge
|
13mm Galvanized hinge
|
|
|||
|
|
Integral frame protective coating
|
Electrostatic spray/straight white plastic powder
|
|
|||
|
|
Top and bottom of middle cabinet
|
80*100*2.5 thick tube
|
|
|||
|
|
Top and bottom of side cabinet
|
40*60*1.7 thick tube
|
|
|||
|
Top
|
External roof
|
t0.5mm Galvanized sheet
|
|
|||
|
|
Interior ceiling
|
t0.3mm 831ceiling board
|
|
|||
|
Panels
|
roof insulation
|
t50mm EPS composite board
|
|
|||
|
|
Side front and rear wall panels
|
t75mm EPS composite board
|
|
|||
|
|
Internal partition
|
t50mm EPS composite board
|
|
|||
|
Floor
|
Middle floor
|
glass magnesium board or cement fiber board
|
|
|||
|
|
Side floor
|
Bamboo flooring
|
|
|||
|
Electric
|
Electrical wiring is installed in strict accordance with moisture-proof specifications, and all electrical products must comply
with CE certification. Connect the circuit according to the circuit engineering specification, indoor: 3 LED lights, 3 five-hole single-open sockets, 3 ten-hole sockets, 3 air-conditioning sockets, and 1 20A leakage protector. |
|
|
|||
|
|
|
|
|
|||
|
|
|
|
|
|||
|
|
Voltage 220V, 50HZ
|
|
|
|||
|
Door
|
Aluminum alloy glass door
|
|
|
|||
|
Window
|
Aluminum window
|
|
|
|||
|
Warranty
|
One year warranty
|
|
|
|||
