Product Details:
|
| Warranty: | 1 Year | After-sale Service: | Online Technical Support |
|---|---|---|---|
| Application: | Hotel | Material: | Sandwich Panel, Steel, Wooden,Log, Other, Steel |
| Use: | Office | Product Type: | Modified Shipping Container |
| Design Style: | Modern | Product Name: | Container Houses Home |
| Keyword: | Mobile Living Container House | Color: | Customized Color |
| Type: | Assembled Fat Pack Container House | Size: | 20ft 0r 40ft |
| Usage: | Workshop Warehouse Construction Office | Advantage: | Fast Install |
| Structure: | Steel Luxury Container House | Door: | Steel Door |
40ft Expandable house Specifications | ||||||
Dimensions | External dimensions(mm) | W6400*L11600*H2480(lower side 2270) | ||||
Internal dimensions(mm) | W6280*L11200*H2280(lower side 2150) | |||||
Folded(mm) | W2160*L11600*H2480 | |||||
Total weight(kg) | 4800kg | |||||
Structure | Top side beam | t2.5mmQ235B | ||||
Bottom side member | t2.5mmQ235B | |||||
End side beam | t2.5mmQ235B | |||||
Side wall frame | t2.5mmQ235B | |||||
Subframe | t2.5mmQ235B | |||||
Hanger | t4mmQ235B | |||||
Folding hinge | 13mm Galvanized hinge | |||||
Integral frame protective coating | Electrostatic spray/straight white plastic powder | |||||
Top and bottom of middle cabinet | 80*100*2.5 thick tube | |||||
Top and bottom of side cabinet | 40*60*1.7 thick tube | |||||
Top | External roof | t0.5mm Galvanized sheet | ||||
Interior ceiling | t0.3mm 831ceiling board | |||||
Panels | roof insulation | t50mm EPS composite board | ||||
Side front and rear wall panels | t75mm EPS composite board | |||||
Internal partition | t50mm EPS composite board | |||||
Floor | Middle floor | glass magnesium board or cement fiber board | ||||
Side floor | Bamboo flooring | |||||
Electric | Electrical wiring is installed in strict accordance with moisture-proof specifications, and all electrical products must comply with CE certification. Connect the circuit according to the circuit engineering specification, indoor: 3 LED lights, 3 five-hole single-open sockets, 3 ten-hole sockets, 3 air-conditioning sockets, and 1 20A leakage protector. | |||||
Voltage 220V, 50HZ | ||||||
Door | Aluminum alloy glass door | |||||
Window | Aluminum window | |||||
Warranty | One year warranty | |||||
