Product Details:
|
| Warranty: | More Than 5 Years | After-sale Service: | Online Technical Support |
|---|---|---|---|
| Application: | Villa | Material: | Sandwich Panel, Steel |
| Use: | Hotel | Product Type: | Detachable Container |
| Design Style: | Modern | Product Name: | Modular Container House |
| Style: | Luxary | Steel Frame: | Galvanized Light Steel Frame |
| Color: | White/Gray/Black Etc. | Application Fields: | Hotel, House, Booth, Office, Shop |
| Floor: | 18mm MgO Board | Window: | PVC Sliding Window |
| Wall/Roof Material: | 50/75mm Z Lock Type EPS Sandwich Panel | Electrical Device: | Switch, Light, Socket, Etc For Customized Standard |
| Port: | Qingdao Shnaghia Tianjing |
|
No.
|
|
Items
|
Size
|
Qty
|
Unit
|
|
1
|
Frame
|
Column2.0mm-2.3mm-2.5mm
|
2480
|
4
|
Pieces
|
|
2
|
|
Upper beam2.0mm-2.3mm-2.5mm
|
2680
|
2
|
Pieces
|
|
3
|
|
Upper beam2.0mm-2.3mm-2.5mm
|
5630
|
2
|
Pieces
|
|
4
|
|
Lower beam2.0mm-2.3mm-2.5mm
|
2680
|
2
|
Pieces
|
|
5
|
|
Lower beam2.0mm-2.3mm-2.5mm
|
5630
|
2
|
Pieces
|
|
6
|
|
Corner piece4.7mm
|
|
8
|
Pieces
|
|
7
|
|
Bolts
|
|
65
|
Pieces
|
|
8
|
Auxiliary part
|
bottom bolt
|
12*80
|
18
|
Pieces
|
|
9
|
|
bottom purlin
|
50*100*2.99
|
9
|
Pieces
|
|
10
|
|
50mm downpipe
|
2700
|
4
|
Pieces
|
|
11
|
|
top sink
|
400*2940
|
2
|
Pieces
|
|
12
|
|
top square tube
|
40*80*2950
|
1
|
Pieces
|
|
13
|
|
|
40*60*2950
|
4
|
Pieces
|
|
14
|
Maintenance section
|
roof tile
|
0.4*840*5630
|
4
|
Pieces
|
|
15
|
|
Insulation cotton
|
|
1
|
Bag
|
|
16
|
|
MgO plane
|
1149*2810
|
5
|
Pieces
|
|
17
|
|
Double-sided 04 steel door
|
970*2030
|
1
|
Pieces
|
|
18
|
|
Reinforced square tube
|
20*40*2.56
|
1
|
Pieces
|
|
19
|
|
Plastic steel sliding window
|
930*1200
|
2
|
Pieces
|
|
20
|
|
Column inner corner edge trim (with fasteners)
|
2480
|
4
|
Pieces
|
|
21
|
|
0.35mm color steel 831 ceiling
|
200*2790
|
7
|
Pieces
|
|
22
|
|
angle iron
|
|
3
|
Pieces
|
|
23
|
|
Drill tail
|
5.5*100
|
20
|
Pieces
|
|
24
|
|
|
5.5*25
|
100
|
Pieces
|
|
25
|
|
Flat drill tail
|
5.5*75
|
80
|
Pieces
|
|
26
|
|
|
5.5*20
|
100
|
Pieces
|
|
27
|
|
|
5.5*50
|
80
|
Pieces
|
|
28
|
|
glue
|
Silicone Weather Resistant Adhesive
|
4
|
Pieces
|
|
29
|
|
|
Styrofoam
|
0.5
|
Pieces
|
|
30
|
|
Double-sided 0.3 rock wool wall panel 50 type
|
2.54
|
15
|
Pieces
|
|
31
|
|
|
1.39
|
2
|
Pieces
|
|
32
|
|
|
0.62
|
1
|
Pieces
|
|
33
|
|
Distributor
|
Distribution box: 1 2P: 1 False alarm: 1 Switch: 1 Light: 1 Three holes: 1 Five holes: 2 Wires: 4 square meters 2.5 square meters
30 meters 1.5 square meters 25 meters |
1
|
Set
|
