Product Details:
|
| Warranty: | More Than 5 Years | After-sale Service: | Online Technical Support |
|---|---|---|---|
| Application: | Office Building | Material: | Sandwich Panel, Steel |
| Use: | Hotel | Product Type: | Flat Pack Container |
| Design Style: | Modern | Product Name: | Modular Container House |
| Style: | Luxary | Steel Frame: | Galvanized Light Steel Frame |
| Color: | White/Gray/Black Etc. | Application Fields: | Hotel, House, Booth, Office, Shop |
| Floor: | 18mm MgO Board | Window: | PVC Sliding Window |
| Wall/Roof Material: | 50/75mm Z Lock Type EPS Sandwich Panel | Electrical Device: | Switch, Light, Socket, Etc For Customized Standard |
| Port: | Qingdao Shnaghia Tianjing |
No. | Items | Size | Qty | Unit | |
1 | Frame | Column2.0mm-2.3mm-2.5mm | 2480 | 4 | Pieces |
2 | Upper beam2.0mm-2.3mm-2.5mm | 2680 | 2 | Pieces | |
3 | Upper beam2.0mm-2.3mm-2.5mm | 5630 | 2 | Pieces | |
4 | Lower beam2.0mm-2.3mm-2.5mm | 2680 | 2 | Pieces | |
5 | Lower beam2.0mm-2.3mm-2.5mm | 5630 | 2 | Pieces | |
6 | Corner piece4.7mm | 8 | Pieces | ||
7 | Bolts | 65 | Pieces | ||
8 | Auxiliary part | bottom bolt | 12*80 | 18 | Pieces |
9 | bottom purlin | 50*100*2.99 | 9 | Pieces | |
10 | 50mm downpipe | 2700 | 4 | Pieces | |
11 | top sink | 400*2940 | 2 | Pieces | |
12 | top square tube | 40*80*2950 | 1 | Pieces | |
13 | 40*60*2950 | 4 | Pieces | ||
14 | Maintenance section | roof tile | 0.4*840*5630 | 4 | Pieces |
15 | Insulation cotton | 1 | Bag | ||
16 | MgO plane | 1149*2810 | 5 | Pieces | |
17 | Double-sided 04 steel door | 970*2030 | 1 | Pieces | |
18 | Reinforced square tube | 20*40*2.56 | 1 | Pieces | |
19 | Plastic steel sliding window | 930*1200 | 2 | Pieces | |
20 | Column inner corner edge trim (with fasteners) | 2480 | 4 | Pieces | |
21 | 0.35mm color steel 831 ceiling | 200*2790 | 7 | Pieces | |
22 | angle iron | 3 | Pieces | ||
23 | Drill tail | 5.5*100 | 20 | Pieces | |
24 | 5.5*25 | 100 | Pieces | ||
25 | Flat drill tail | 5.5*75 | 80 | Pieces | |
26 | 5.5*20 | 100 | Pieces | ||
27 | 5.5*50 | 80 | Pieces | ||
28 | glue | Silicone Weather Resistant Adhesive | 4 | Pieces | |
29 | Styrofoam | 0.5 | Pieces | ||
30 | Double-sided 0.3 rock wool wall panel 50 type | 2.54 | 15 | Pieces | |
31 | 1.39 | 2 | Pieces | ||
32 | 0.62 | 1 | Pieces | ||
33 | Distributor | Distribution box: 1 2P: 1 False alarm: 1 Switch: 1 Light: 1 Three holes: 1 Five holes: 2 Wires: 4 square meters 2.5 square meters 30 meters 1.5 square meters 25 meters | 1 | Set |
