Product Details:
|
| Warranty: | More Than 5 Years | After-sale Service: | Online Technical Support, Other, CAD, 3D Plan |
|---|---|---|---|
| Application: | Hospital, Hotel, House, Booth, Office, Shop | Use: | Carport, Hotel, House, Shop |
| Product Type: | Container Houses | Design Style: | Modern |
| Size: | 20ft 0r 40ft | Color: | White/Gray/Black Etc. |
| Material: | Steel+ Sandwich Board | Type: | Modern |
| Project Solution Capability: | Graphic Design, 3D Model Design, CAD | Port: | QIngdao,Shanghai ,Tanjing |
Name | Items | Size | Qty | Unit |
Frame | Column2.0mm-2.3mm-2.5mm | 2480 | 4 | Pieces |
Upper beam2.0mm-2.3mm-2.5mm | 2680 | 2 | Pieces | |
Upper beam2.0mm-2.3mm-2.5mm | 5630 | 2 | Pieces | |
Lower beam2.0mm-2.3mm-2.5mm | 2680 | 2 | Pieces | |
Lower beam2.0mm-2.3mm-2.5mm | 5630 | 2 | Pieces | |
Corner piece4.7mm | 8 | Pieces | ||
Bolts | 65 | Pieces | ||
Auxiliary part | bottom bolt | 12*80 | 18 | Pieces |
bottom purlin | 50*100*2.99 | 9 | Pieces | |
50mm downpipe | 2700 | 4 | Pieces | |
top sink | 400*2940 | 2 | Pieces | |
top square tube | 40*80*2950 | 1 | Pieces | |
40*60*2950 | 4 | Pieces | ||
Maintenance section | roof tile | 0.4*840*5630 | 4 | Pieces |
Insulation cotton | 1 | Bag | ||
MgO plane | 1149*2810 | 5 | Pieces | |
Double-sided 04 steel door | 970*2030 | 1 | Pieces | |
Reinforced square tube | 20*40*2.56 | 1 | Pieces | |
Plastic steel sliding window | 930*1200 | 2 | Pieces | |
Column inner corner edge trim (with fasteners) | 2480 | 4 | Pieces | |
0.35mm color steel 831 ceiling | 200*2790 | 7 | Pieces | |
angle iron | 3 | Pieces | ||
Drill tail | 5.5*100 | 20 | Pieces | |
5.5*25 | 100 | Pieces | ||
Flat drill tail | 5.5*75 | 80 | Pieces | |
5.5*20 | 100 | Pieces | ||
5.5*50 | 80 | Pieces | ||
glue | Silicone Weather Resistant Adhesive | 4 | Pieces | |
Styrofoam | 0.5 | Pieces | ||
Double-sided 0.3 rock wool wall panel 50 type | 2.54 | 15 | Pieces | |
1.39 | 2 | Pieces | ||
0.62 | 1 | Pieces | ||
Distributor | Distribution box: 1 2P: 1 False alarm: 1 Switch: 1 Light: 1 Three holes: 1 Five holes: 2 Wires: 4 square meters 2.5 square meters 30 meters 1.5 square meters 25 meters | 1 | Set |
